General Specification
Standard ROCKSHIELD™ sheet size

The supplied Arihant Shree specification lists the following standard sheet dimensions.

1170
Width / dimension
mm
1400
Width / dimension
mm
1900
Width / dimension
mm
All listed sheet options: 3000 mm length
Plate Size Reference

Standard dimensions, clearly presented.

ROCKSHIELD plates are normally listed in the standard sheet sizes of 1170 x 3000, 1400 x 3000, 1900 x 3000 mm.

1170 × 3000 mm

One of the standard sheet sizes specified in the supplied ROCKSHIELD content.

1400 × 3000 mm

A second standard sheet dimension listed in the supplied specification.

1900 × 3000 mm

A third standard sheet dimension listed in the supplied specification.

Industrial Applications

ROCKSHIELD™ application sectors.

The following applications are retained from the supplied Arihant Shree ROCKSHIELD wear plate specification.

01
Application Sector

Thermal Power Stations

ROCKSHIELD™ plate applications listed for thermal power stations.

  • Vibratory feeders
  • Coal Feeder Plates
  • Coal Handling plant Chutes
  • Feeder Breaker and Crusher liner Plates
  • Surge hoppers
  • Scroll liners
  • Liner for Fly ash hopper
  • Liner for Transition plate.
02
Application Sector

Cement Plants

ROCKSHIELD™ plate applications listed for cement plants.

  • Clinker dust /Raw mill cyclone liners
  • Raw Mill body liners
  • Ducts and chutes
  • Flap and Valve Body
  • Crusher liners
  • Coal Mill Fan Blades
  • Cement Mill Impeller
  • Ventilators
  • Sepax Air Separator Vanes/Louvre's
  • Fan casing liners
  • Chutes and skirt liners
  • Breaker plates
  • Hammer Millliners
  • Guide Vanes /classifier Static vanes
  • Hoppers
  • Feed Pipes/ Chutes
  • Roller cover Ring
  • Raw Mill Wear Guard
  • Nozzle segment for Raw Mill
  • Rotary/Apron Feeder liners
  • Atox Mill body liners
  • Polycom Hydraulic Gate liner
  • Armour Ring for Raw mill
  • Bucket wheel chute
03
Application Sector

Mines / Collieries

ROCKSHIELD™ plate applications listed for mines / collieries.

  • Transfer Chutes
  • Conveyor chute chutes and liner
  • Hopper liner
  • Coal crusher liner
  • Skirt and chute liner
  • Pathways
  • Vibratory feeder liner
  • Reject Bin liner
  • Slurry pipes
  • Deck and skirting plates
  • Apron Feeders
  • Dump Truck Body
  • Mines and quarry skips
  • Ore scarpers
  • Grizzly Bars and side plates
  • Reclaimer liner
  • Ore cars
  • Drag line Buckets
04
Application Sector

Steel Plants

ROCKSHIELD™ plate applications listed for steel plants.

  • Screen Plates
  • scroll casing liners
  • Sinter Fan Blades
  • Crusher liners
  • Transfer chutes
  • Coke Guide plates
  • Bunker liners
  • Cyclones
  • Chain Guides
  • Raw Mill bins
  • Vibratory Feeder liners
  • Storage hoppers
  • Scrubber Discharge chute
  • Shell liner for Dryer
  • Pipe for Coal Mill of Blast Furnace
  • Product feed feeding chute
  • Liner for DP Flap
  • Liners for Feeder of Sinter plant.
05
Application Sector

Earth Moving Equipment

ROCKSHIELD™ plate applications listed for earth moving equipment.

  • Bull Dozer Blades
  • Scrapers
  • Compact Rolls
  • Loader Buckets.
06
Application Sector

Chemical Process Plant & Pneumatic Conveying

ROCKSHIELD™ plate applications listed for chemical process plant & pneumatic conveying.

  • Mixer paddles
  • Concrete Mixers
  • Clinker chutes
  • Suction sweeper blades
  • Spouts and Troughs.
FAQ

Wear plate sizes & applications FAQ

The supplied Arihant Shree content states the standard sheet sizes as 1170 x 3000, 1400 x 3000, 1900 x 3000 mm.

The supplied specification lists Thermal Power Stations, Cement Plants, Mines/Collieries, Steel Plants, Earth Moving Equipment, and Chemical Process Plant and Pneumatic Conveying applications.

The source lists applications including clinker dust/raw mill cyclone liners, raw mill body liners, ducts and chutes, crusher liners, coal mill fan blades, fan casing liners, hoppers, feeder liners, armour rings and other cement-plant components.

Yes. The supplied content lists Mines/Collieries applications including transfer chutes, hopper liners, coal crusher liners, slurry pipes, apron feeders, dump truck bodies, grizzly bars and side plates, reclaimer liners, ore cars and drag line buckets.
Arihant Shree • ROCKSHIELD™

Explore the right wear plate application.

Review the standard plate sizes and application areas listed for ROCKSHIELD™ wear plates.
